PTFE Frame SUS Inside Large Tank Immersion Heaters 400V 12KW 3 Phase

Large Image : PTFE Frame SUS Inside Large Tank Immersion Heaters 400V 12KW 3 Phase

Product Details:

Place of Origin:	China
Brand Name:	Surplus
Certification:	ISO9001
Model Number:	PTFE immersion Heater 14

Payment & Shipping Terms:

Minimum Order Quantity:	1 PCS
Price:	Contact Us
Packaging Details:	Wooden Case or Carton Box
Delivery Time:	10-15 working days
Payment Terms:	TT, Paypal, Western Union
Supply Ability:	50 PC/Month

Contact Now

PTFE Frame SUS Inside Large Tank Immersion Heaters 400V 12KW 3 Phase

Description

Name:	400V 12KW 3 Phase Double Sets Assembly PTFE Immersion Heater For Large Plating Tanks	Supply Voltage (V/Phase)::	110V-480V
Power(KW):	1KW-6KW	Type Of Temperature Control:	Overheat Protection
Application:	Acid Heating And Corrosive Chemical Heating	Frame Material:	PTFE
Inside Material:	SUS	Cable Length:	2 Meters/3meters/others
Highlight:	12KW Large Tank Immersion Heaters , Large Tank Immersion Heaters 400V , PTFE Frame Immersion Heaters

400V 12KW 3 Phase Double Sets Assembly PTFE immersion Heater For Large Plating Tanks

PRODUCT DESCRIPTION

Excellent chemical resistance to aggressive acids.

FEATURES
- PTFE sleeved 304 stainless elements inert to most solutions up to 212°F (100°C).
- Low watt density design 10 watts/square inch (1.5w/cm²).
- Vapor resistant, flame retardant polypropylene terminal enclosure with 3 ft (.9m) flexible PVC liquid tight conduit.
- Grounded internal metal element and built in thermal protector. Replaceable P1 protector standard for solutions up to 180°F(82°C).
- Certification: cULus. CE certified and CSA
SPECIFICATIONS
- 3000 - 18000 watts
- 120 to 600 volts (600 volts on 12,000 watts or lower only)
OPTIONS AVAILABLE (CONSULT FACTORY)
- Resettable thermal protectors
- Polypropylene guards (sold separately)
- Custom configurations and lengths
- Custom wire and conduit lengths

FLAT ASSEMBLY TYPE – PTFE Immersion Heater

Universal ‘all plastic’ model
Ideal for important powers (from 6kW)
Up to 48 kW
Ideal for large tanks

Universal model for all types of installation such as side of tank, bottom of tank with feet or on slidings.
Rigid structure ideal for important powers.

Assembly type F
On a plastic rod frame PVDF or PP.
Standard configuration : heating cable coated Teflon® FEP and PP or PVDF rod frame.
For use on the side or at the bottom of the tank.

Others Applications

Precious Metal Deposition
Engineered to meet the most stringent requirements, accurate and reliable Heaters in Precious Metals' Deposition reduce materials waste. Low ripple Power Supplies provide clean and smooth direct current (DC), precision results while also saving on materials.

Products For General Metal Finishing

MOTS SINGLE
MOTS Single Heater – Chemical and Small Immersion Heater: Metal over the side single heater. Single or three phase. 1000-12000 watts, 120-600 volts.

PTFE Frame SUS Inside Large Tank Immersion Heaters 400V 12KW 3 Phase 0

MOTS SINGLE – DAS, PHOSPHATE
MOTS Single DAS Phosphate Heater – Top Portable Electric Immersion Heaters: Phosphate, metal over the side heater. Single or three phase. 1000-10000 watts, 120-600 volts.

PTFE Frame SUS Inside Large Tank Immersion Heaters 400V 12KW 3 Phase 1

MOTS TRIPLE – L SHAPED, DERATED
Derated, low watt density, L-shaped, bottom style metal over the side heater. 1500-18000 watts, 120-480 volts.

PTFE Frame SUS Inside Large Tank Immersion Heaters 400V 12KW 3 Phase 2

MOTS SINGLE – BOTTOM, DERATED
Derated, low watt density, L-shaped, bottom, metal over the side Immersion Heater. Single or Three phase. Three phase. 500-6000 watts, 120-480 volts.

. PTFE Frame SUS Inside Large Tank Immersion Heaters 400V 12KW 3 Phase 3

MOTS TRIPLE – L SHAPED
L-shaped, bottom style metal over the side heater. Three phase. Single or three phase. 3000-36000 watts, 200-600 volts.

PTFE Frame SUS Inside Large Tank Immersion Heaters 400V 12KW 3 Phase 4

6HS SERIES – TUBULAR
Over the side, 6 element, tubular heater. Three phase. 6000-21000 watts, 208-600 volts.

PTFE Frame SUS Inside Large Tank Immersion Heaters 400V 12KW 3 Phase 5

Anodizing
Anodizing is an electrochemical process of converting a metal surface into an oxide layer. Mainly aluminum is used for anodizing, although other nonferrous metals, such as titanium and magnesium, can also be anodized. The metal part is connected as the anode and immersed into an acid electrolyte bath, where an electric current is applied to grow the oxide layer from the piece. The resulting surface finish will provide functional properties as corrosion-resistance and durability, as well as decorative properties. Surplus heaters provide beautiful, precise finishes. Surplus power supplies deliver high current, high accuracy, and high energy efficiency to meet a modern anodizing process's requirements.

Products For Anodizing

MOTS SINGLE – BOTTOM, DERATED
Derated, low watt density, L-shaped, bottom, metal over the side Immersion Heater. Single or Three phase. Three phase. 500-6000 watts, 120-480 volts.

. PTFE Frame SUS Inside Large Tank Immersion Heaters 400V 12KW 3 Phase 6

MOTS TRIPLE – L SHAPED
L-shaped, bottom style metal over the side heater. Three phase. Single or three phase. 3000-36000 watts, 200-600 volts.

PTFE Frame SUS Inside Large Tank Immersion Heaters 400V 12KW 3 Phase 7

6HS SERIES – TUBULAR
Over the side, 6 element, tubular heater. Three phase. 6000-21000 watts, 208-600 volts.

PTFE Frame SUS Inside Large Tank Immersion Heaters 400V 12KW 3 Phase 8
