Industrial Coil-shaped Teflon(PTFE) Electric Immersion Photovoltaic Heater

PV or Solar Cells

Usually made of silicon, high efficiency, low-cost, long-life Photovoltaic (PV) solar cells are made by depositing PV material layers on a supporting material. Layering multiple semiconductors to create multijunction cells increases efficiency.

PFA Immersion Frame Heaters are great for heating fluid baths to a constant temperature

Product Description

Industrial Immersion Heaters - Fluoropolymer (PFA) Immersion Heaters

High performance, non-corrodable electric tank heater

The Popular is manufactured from high integrity fluoropolymers to give best protection against deterioration and to give high performance in corrosive solutions.

Now available - fitted to order

OTP: Protect your plant from catastrophic heater failure.

Switches the heater off if the element gets too hot.

HPD: Protect your heater from low level failure.

Simple conductive level device built into the heater.

The element has an open construction to allow free flow of liquid across the surface and to limit solid retention, which is particularly important when used in solutions which generate solid deposition such as electroless nickel and copper plating processes.

The heater is thin enough to fit easily into confined spaces, for example behind anode baskets. The Popular can be supplied with hanging brackets for vertical mounting or standoffs for horizontal mounting. The integral BraudeFlex lead has no junctions and is continuous and flexible.

Typical applications: Electroplating, electroless plating, anodising, acid pickling, frost protection for chemical storage tanks, chemical processes, marine water tanks, many more.

Other Applications(Other products)

Flammable Solvent Heating
Products designed to safely heat IPA and low flash-point solvents, meeting the most stringent cleanliness requirements to support next-generation semiconductor node technologies.



Products For Flammable Solvent Heating
PFA Inline Chemical Heater	PTFE Inline Chemical Heater	Inline Chemical Heater

Precious Metal Deposition
Engineered to meet the most stringent requirements, accurate and reliable Heaters in Precious Metals' Deposition reduce materials waste. Low ripple Power Supplies provide clean and smooth direct current (DC), precision results while also saving on materials.

Products For General Metal Finishing
MOTS SINGLE MOTS Single Heater – Chemical and Small Immersion Heater: Metal over the side single heater. Single or three phase. 1000-12000 watts, 120-600 volts.	MOTS SINGLE – DAS, PHOSPHATE MOTS Single DAS Phosphate Heater – Top Portable Electric Immersion Heaters: Phosphate, metal over the side heater. Single or three phase. 1000-10000 watts, 120-600 volts.	MOTS TRIPLE – L SHAPED, DERATED Derated, low watt density, L-shaped, bottom style metal over the side heater. 1500-18000 watts, 120-480 volts.
MOTS SINGLE – BOTTOM, DERATED Derated, low watt density, L-shaped, bottom, metal over the side Immersion Heater. Single or Three phase. Three phase. 500-6000 watts, 120-480 volts. .	MOTS TRIPLE – L SHAPED L-shaped, bottom style metal over the side heater. Three phase. Single or three phase. 3000-36000 watts, 200-600 volts.	6HS SERIES – TUBULAR Over the side, 6 element, tubular heater. Three phase. 6000-21000 watts, 208-600 volts.
9HX SERIES Low watt density, 9 element fluoropolymer (PTFE) sleeved 304 stainless elements inert to most solutions. Three phase. 3000-18000 watts, 208-600 volts.	6HX SERIES Low watt density, 6 element fluoropolymer (PTFE) sleeved 304 stainless elements inert to most solutions. Three phase. 2000-12000 watts, 208-600 volts.	3HXOL SERIES Low watt density, 3 element, bottom heater. Fluoropolymer (PTFE) sleeved 304 stainless elements inert to most solutions . 3000-18000 watts, 208-480 volts.
